Multi stage centrifugal pumps series SKP are single or multi stage centrifugal pumps in horizontal or vertical construction. With this series the required pressure increase can be varied brightly, according to the mutable number of stages. Some of the pumps are constructed for system pressures up to 250 bar, depending on the material combination. SKP-pumps are as well available in accordance with API 610 - BB4 or BB5. Balancing of axial thrust is enabled by balancing holes in the impellers for the standard versions. Double casing version for higher pressure will have a back to back arrangement of the impellers to equalize the axial thrust.

Fields of application

Main field of application for multi stage centrifugal pumps series SKP is the increase of pressure in plant construction, as well as process technology. These pumps are suitable for most application scenarios, due to the eligibility of use in high system pressures as well as the different material combinations possible. Our customers currently use our SKP-pumps in the following applications:

• Booster systems

• Plant construction

• Industry

• Process technology

• Reverse osmoses

Operating Data

Flow: Q up to 470 m³/h

Total head: H up to 580 m (higher head is available on request)

Motor power: P from 0.75 kW to 250 kW
