• Single-stage centrifugal pumps for handling of abrasive and corrosive liquids

• All components in contact with the liquid are made of SICcast, a non-metallic mineral cast material made of silicon carbide.
  (SICcast EP135 consists of silicon carbide and epoxy resin, forming a metal-free, non-magnetic, noise- and vibration-reducing material with diamond-like hardness)

• Vertical and submersible option available

Technical data MC:

• Max. Pump Size: DN 300 (12“)

• Max. Pressure: 16 bar (230 PSI)

• Max. Flow: 1500 m³/h (6600 gpm)

• Max. Head: 90 m (395 ft)

• Max. Rotating Speed: 3600 rpm

Technical data MCC:

• Max. Pump Size: DN 1000 (40“)

• Max. Pressure: 6 bar (90 PSI)

• Max. Flow: 20000 m³/h (88000 gpm)

• Max. Head: 40 m (131 ft)

• Max. Rotating Speed: 1200 rpm
